Avid Pro Tools MTRX Base Unit Multi-Format I/O Audio Interface

Brand: AvidSKU: SP-NAVI012Condition: Special Order


  • z  Special Order
    This is a special order item. Feel free to call us for availability.
  •  We'll get it FAST!
    Order now to reserve one. We'll get it to you quickly due to our great relationship with Avid. You'll get a delivery estimate in 1 business day.
  • For more information about special orders, please visit our FAQ Page or give us a call.

About this Product

This is a brand new Avid Pro Tools MTRX Base Unit Multi-Format I/O Audio Interface.

Product Details:
Developed for Avid by Digital Audio Denmark, the Pro Tools | MTRX is a powerful multi-format I/O for Pro Tools. It can be used as both a Pro Tools HD Interface or an integrated monitor section for Avid Control Surfaces and Pro Tools, for use in the most demanding Immersive Post Production and Music Studios.

Features include modular interface options, Eucon controlled monitor functionality, a massive integrated router and exceptionally high quality analog input, output and Mic Pre card options.</p><p>MTRX Base Unit comes with 16 AES I/O, a Coaxial MADI I/O pair, 2 mini DigiLink, Pro|Mon2 Eucon Monitoring, DADMan Application for remote control and Config from Mac or PC.

What's Included:

  • Pro Tools | MTRX base unit* (with eight empty card slots, ready to be configured)
  • Pro | Mon 3 monitoring control
  • DADman software
  • DigiLink Mini cable
  • DigiLink I/O License
  • AC power cable


  • System Requirements
    • Pro Tools | HDX or Pro Tools | HD Native system running Pro Tools | Ultimate 2019.12 or later and DADman 5.4.1 or later.
  • Analog and digital I/O
    • Configurability: Customizable I/O with eight option card slots*
    • Mic/Instrument inputs: None—add mic preamps and analog inputs (DB25) via option cards*
    • Analog Line I/O: None—add line-level inputs (DB25) via option cards*
    • ADAT I/O: None
    • AES/EBU I/O: Eight AES pairs (16 mono) via two DB25 connectors; expandable via option cards*
    • Dante I/O: None—add Dante I/O via option cards*
    • DigiLink I/O: Two 32-channel DigiLink Mini connectors (64 channels total); expandable to 448 DigiLink I/O channels via option cards*
    • MADI I/O: 64 channels (BNC); expandable via option cards*
    • Dedicated monitor outputs: None
    • Headphone outputs: None
  • Monitoring and routing
    • Cross-point digital matrix: 1,500 x 1,500
    • Summing matrix with monitor profiles: 256 x 16, Monitor Groups, Fold Downs, Group Formats
    • Integrated speaker calibration: None—add the SPQ Speaker Processing Card* to get 1,024 filters on 128 channels, with delay management adjustable up to 800 ms per channel
  • Additional specifications
    • EUCON integration: Yes
    • System sync: Word Clock/video black burst (VBB) via BNC connectors; AES11 input
    • Supported sample rates: 44.1 kHz–384 kHz
    • Power supply: Dual (internal)
    • Chassis: 2U 19" rack-mountable unit
  • * All option cards for Pro Tools | MTRX are sold separately.

Warranty Period:  1 Year

We are an authorized Avid dealer.
