When it comes to professional audio recording, few names carry the weight and reputation of Focusrite. From the budget-friendly Scarlett line beloved by home producers, to the elite RedNet series powering mission-critical studios and live sound rigs, Focusrite offers robust solutions for nearly every audio environment.
A Brief Look at Dante: The Backbone of RedNet
At the heart of the RedNet ecosystem is Dante — a networked audio protocol that replaces bulky, failure-prone analog multicore snakes with a sleek, flexible digital infrastructure.
With just a single Gigabit Ethernet cable, users can transmit up to 512 channels of bidirectional, uncompressed audio, dramatically simplifying setups while enhancing scalability and reliability.
It’s tailor-made for large-scale studios, broadcast facilities, and live venues where distributed audio workflows are essential.
Meet The RedNet TNX Interface
Enter the RedNet TNX: a Thunderbolt-to-Dante interface that brings ultra-low latency, high-channel-count connectivity to your DAW with plug-and-play simplicity. Supporting up to 256x256 channels of pristine 24-bit/192kHz audio, the TNX allows you to access and route your entire Dante network through a single Thunderbolt cable — making it a powerful, portable interface for AoIP (Audio-over-IP) workflows.
Take a look at these features to learn more about this powerful interface.
Massive Channel Count, Minimal Footprint
Right out of the box, the RedNet TNX delivers 128x128 channels of uncompressed 24-bit/192kHz audio over Thunderbolt™ 3. For studios and facilities that demand even more, the optional Dante Ready™ upgrade unlocks 256x256 channels at 24-bit/96kHz, all through a single Thunderbolt connection. That’s serious I/O density in a compact form factor.
Ultra-Low Latency Performance
Whether you're tracking a full band or mixing immersive audio formats, latency can make or break your workflow. The TNX is engineered for ultra-low round-trip latency, ensuring real-time responsiveness and tight sync across your entire Dante network.
Dual Thunderbolt™ 3 Ports with Power Delivery
The TNX features two Thunderbolt™ 3 ports, each capable of delivering 15W of power. This allows for daisy-chaining additional Thunderbolt devices and powering peripherals.
No PCIe Card Required
Because it connects directly to the computer via Thunderbolt 3, no additional PCIe card is required to be installed in the computer. This makes the TNX a great option for Thunderbolt 3 equipped laptops and desktops that do not have PCIe expandability, such as the MacBook Air, MacBook Pro, Mac Mini, or Mac Studio.
Dante Network Integration
With dual RJ-45 Ethernet ports, the TNX supports both switched and redundant Dante modes, offering flexibility and fail-safe operation for mission-critical environments. It’s also AES67 and SMPTE ST 2110 compliant, making it a perfect fit for broadcast and post-production workflows.
Seamless Software Control
The TNX integrates tightly with RedNet Control, Focusrite’s centralized software for managing and monitoring all RedNet devices. From routing to device status, everything is accessible in one intuitive interface — no need to juggle multiple apps or hardware panels.
Cross-Platform Compatibility
Whether you're running macOS (including Apple Silicon) or Windows, the TNX is plug-and-play ready. It supports CoreAudio, ASIO, and WDM drivers, ensuring smooth integration with virtually any DAW or audio application.
Built for the Road and the Rack
Despite its high channel count, the TNX is portable and rugged, with exposed M5 threads for secure rack mounting. It’s equally at home in a fixed installation or a mobile production rig, offering flexibility without compromise.
Future-Proofed and Backed by Focusrite
With a three-year warranty, 24/7/365 technical support, and a design that anticipates evolving AoIP standards, the RedNet TNX is built not just for today’s workflows — but for tomorrow’s as well.
The RedNet TNX isn't designed for every setup — but for professionals who demand the power, flexibility, and scalability of a Dante-based workflow, it stands out as a top-tier solution worth serious consideration.
